MAKIN' WAVES

Packed with features and made for specifically for marine use, KICKER gives you the deep, loud bass your boat needs.

FEATURES

Four-Ohm Voice Coil
Injection-Molded Polypropylene Cone
Co-molded Santoprene® Surround
UniPlate™ Back Plate And Pole Piece
Thick Tinsel Leads
Large Ceramic Magnet
Polymer Basket Resists Corrosion
Protective Terminal Cap
Stainless Mounting Hardware Included
Meets or Exceeds ASTM Standards for UV and Salt/Fog Exposure
(ASTM B117 200 hr. Salt Fog Test) (ASTM G154 400 hr. Accelerated UV Test)
Want setup help? Go to KICKERU for a free woofer and amplifier configuration app!
*The KM 10-inch Subwoofer works best with a sealed or ported enclosure and 175 watts of recommended power. See below for more details.

Specifications
Thiele/Small Parameters
TS Parameters PDF link 45KM104 T/S Parameters PDF
Woofer(in,mm)
10, 25
Impedance (OHMS)
4 SVC
Peak Power (watts, per ANSI/CTA-2031-A)
350
Recommended Amplifier Power (watts RMS)
175
Sealed Enclosure Volume Min-Max(ft³, L)
1-2.4, 28.3-68
Vented Enclosure Volume Min-Max(ft³, L)
1.25-1.75, 35.4-49.6
Frequency Response(Hz)
30-500
Mounting Depth(in, cm)
5, 12.7
Hole Diameter(in, cm)
9-3/16, 23.2
Outer Diameter(in, cm)
10-11/16, 27.1
What's in the Box:
1 - 10" Woofer
1 - Back gasket
8 - Mounting screws
8 - Mounting screw clips
1 - Manual
