Black Bezel

9 - 36 Volt 106 Watt

Driving Beam Pattern 25 Degrees

12 x 3 Watt High Intensity LP LED's and 7 x 10 Watt High Intensity LP LED's

11,000 Raw and 8,800 Effective Lumens and 6,000K

1 Lux @ 538m and 289,000cd Peak Beam Intensity

Current Draw: 7.1amp @ 12 Volt and 3.4amp @ 24 Volt

Combined Polycarbonate Reflector Focusing Optic Drive Technology with Lexan Polycarbonate Lens

Integrated Electronic Thermal Management (ETM)

Black Powder coated Die Cast Aluminium (ADC12) Housing with integrated Heat-Sink and Pressure Equalising Vent

Stainless Steel (SUS304) Multiple Bolt Mount Bracket and Hardware

500mm Lead with 2 Pin Deutsch Plug

Over and Under Voltage Protection

Reverse Polarity Protection

UV, Water and Shock resistant to 15G

Anti Rust, corrosion and freezing resistance

50,000 Hours LED Lifespan

ECE R10 and CE Approved

IP68 and IP69K Rating

Environment Temperature: -40°C ~ +60°C

2 Year Warranty

Weight: 1.4kg
