Visible reset lever shows open condition
Ignition protected - Meets SAE J1171. Safe for installation aboard gasoline powered boats
Weather Resistant IP67
Combines switching and circuit breaker function into one unit
"Trip Free" - cannot be held closed after trip

Specifications

Circuit Breakers
Maximum Voltage	48V DC
Circuit Breaker Class	Type III – switchable/manual reset – trip free
Circuit Breaker Type	Single Pole Thermally Responsive Bi-metal Blade
Interrupt Capacity	3000A @ 48V
Minimum Operating Temp	-32° C
Maximum Operating Temp	82° C
Ignition Protected	Meets SAE J553, J1625, J1171, UL1550
Splash & Dust Proof	IP67
UL Rating	Housing is Thermal Plastic UL Rated, 94V0
Terminal Stud	25-70A - M6 (accepts 1/4″ ring Terminal) 80-250A - M10 (accepts 3/8″ ring Terminal)
Terminal Stud Torque	50 in-lb (5.65 Nm)
Weight	0.23 kg

Note: Specifications subject to change without notice.

Enerdrive Surface Mount Breakers 3/8 Stud 100A

SKU: EN-RCB100

$58.90 MATES’ RATE

Unlock Mates'Rate and Save. Login or Join Free

SAVE $3.10

REG $62.00

NSW, QLD & VIC Order Express by 17th Dec for Christmas delivery. T&Cs apply.

Ships in 7 days

$62.00 REG

$58.90 MATES’ RATE

Visible reset lever shows open condition
Ignition protected - Meets SAE J1171. Safe for installation aboard gasoline powered boats
Weather Resistant IP67
Combines switching and circuit breaker function into one unit
"Trip Free" - cannot be held closed after trip

Circuit Breakers
Maximum Voltage	48V DC
Circuit Breaker Class	Type III – switchable/manual reset – trip free
Circuit Breaker Type	Single Pole Thermally Responsive Bi-metal Blade
Interrupt Capacity	3000A @ 48V
Minimum Operating Temp	-32° C
Maximum Operating Temp	82° C
Ignition Protected	Meets SAE J553, J1625, J1171, UL1550
Splash & Dust Proof	IP67
UL Rating	Housing is Thermal Plastic UL Rated, 94V0
Terminal Stud	25-70A - M6 (accepts 1/4″ ring Terminal) 80-250A - M10 (accepts 3/8″ ring Terminal)
Terminal Stud Torque	50 in-lb (5.65 Nm)
Weight	0.23 kg
