Black polymer body with either black or white polymer splash guard.
- Multiple styles of splash guards, connection options to fit 5/8 inch vent line hoses.
- Helps reduce system costs by allowing for less expensive, smaller vent lines and hose clamps.
- Allows vapour to vent from the tank during thermal expansion of fuel, and fresh air flow into the tank during thermal contraction of fuel and when the engine is running.
- Deflector-style vent opening reduces water volume entering assembly.
- Internal P-Trap and check valve prevent water from passing through assembly into the fuel system.
- 90° hose connection (to vent axis).
PART NUMBER |
CAP COLOUR |
MATERIAL |
HOSE SIZE |
TYPE |
MAX. HULL THICKNESS |
29317 |
Black |
Polypropylene |
5/8" |
90° |
5/8" |
29319 |
White |
Polypropylene |
5/8" |
90° |
5/8" |
