Description
87 Model 20 L.E.D lamps are sonically sealed acrylic lamps with a multi-voltage circuitry of 10–30V and hard-wired leads. Less expensive than the flush mounted polycarbonate 18 series lamps, the 20 series are a low profile surface mounted alternative. These lamps meet the requirements of ADR 74/00 as an amber side marker and are ideal for
SPECIFICATIONS
-
Technical Information
| INPUT VOLTAGE RANGE | 10-30 Volt |
|---|---|
| CURRENT DRAW | 0.04A |
| IP RATING | IP66 and IP68 |
| SIZE | 124 x 39mm |
| CANDELA RATING | 24 |
| ADR | 47/00 31156, 49/00 31155 |
-
Dimensions
Specifications
| SKU | 92010 |
|---|---|
| Barcode # | 9314464920103 |
| Brand | Narva |
| Shipping Weight | 0.0800kg |
| Shipping Width | 0.055m |
| Shipping Height | 0.100m |
| Shipping Length | 0.195m |
Narva 10-30 Volt Model 20 Led Rear End Outline Marker Lamp (White)
SKU: 92010
Ships in 7 days (Christmas delays possible)
More infoMake 4 payments of $15.00 over 8 weeks and get it now!
Calculate Shipping
Description
87 Model 20 L.E.D lamps are sonically sealed acrylic lamps with a multi-voltage circuitry of 10–30V and hard-wired leads. Less expensive than the flush mounted polycarbonate 18 series lamps, the 20 series are a low profile surface mounted alternative. These lamps meet the requirements of ADR 74/00 as an amber side marker and are ideal for
SPECIFICATIONS
-
Technical Information
| INPUT VOLTAGE RANGE | 10-30 Volt |
|---|---|
| CURRENT DRAW | 0.04A |
| IP RATING | IP66 and IP68 |
| SIZE | 124 x 39mm |
| CANDELA RATING | 24 |
| ADR | 47/00 31156, 49/00 31155 |
-
Dimensions
Specifications
| SKU | 92010 |
|---|---|
| Barcode # | 9314464920103 |
| Brand | Narva |
| Shipping Weight | 0.0800kg |
| Shipping Width | 0.055m |
| Shipping Height | 0.100m |
| Shipping Length | 0.195m |
