2.7" Gauge Mount Infotainment System
GIVE YOUR BOAT OR OFF-ROAD VEHICLE A MEDIA OVERHAUL
The SPXM1 digital media player is proof that big things come in small packages. SPXM1 features a 2.7-inch full-color display and LED-backlit buttons for viewing in all lighting situations including while wearing polarized sunglasses.
Designed For Reliablity
The Stinger SPXM1 features a 2.7-inch full-color display and LED-backlit buttons for viewing in all lighting situations including while wearing polarized sunglasses. Whether your off-shore fishing or off-roading.
Stinger's SPXM1 is engineered to last with an IPX6-rated optical bonded front panel and conformal-coated circuit board allowing it to withstand those harsh outdoor elements.
Audio Expandability
The SPXM1 both front and selectable rear/subwoofer RCA outputs for easy connection to Powersport amplifiers whether your wanting to run multiple speakers and/or a subwoofer.
Easily tweak the sound to your liking using the onboard 7 band EQ (with upto eight presets) and inbuilt high and low pass filters to suit your music tastes and installation and subwoofer-level control, your able to adjust the bass level (if fitted).
Not using external amplifiers? the SPXM1's built-in high-power 45 x 4 amplifier will allow upto 4 speakers to be connected to enjoy your tunes.
Connectivity Plus
Packed with audio sources including
- Global AM/FM/weather-tuner (can tune odd and even-numbered stations throughout the world!)
- USB input for MP3/WMA/WAV/FLAC files
- Bluetooth Audio
- Wired AUX RCA input
Increase your vehicle safety with the included RCA camera input, selectable from the main menu.
Keep and eye on your battery voltage with the easy access voltage gauge with low voltage alert.
Your Command Center
Make the SPXM1 is your new command center. Compatible with the optional Stinger SwitchHUB (SPXSH440, available separately) you are capable of controlling up to 4 devices (100A total load).
Control external devices like lighting, amplifiers, pumps, compressors and more.
For quick and easy access to those controls, SPXM1 uses a dedicated switch panel button, so the onboard display shows all four devices' statuses at once.
With the optional SPXR2 marine grade controller, you can remotely control your music from the press of a button (available separately).
SPXM1 becomes an ALL-IN-ONE Digital Media and Control Center, keeping things clean and clutter-free.
Multiple Mounting Options
With 3" mounting design, the SPXM1 can be easily mounted into many boats or ATVs in place of many factory fitted marine units or can be installed by simply cutting a 3" hole.
For vehicles with larger factory radio, optional accessories SEADASH3W / SEADASH3B are available for clean mounting option.
Optional Accessories
Customize Your Installation
Optional accessories for the SPXM1 include
- External wired marine remote control (SPXR2)
- 4 Way Solid State Relay/Power Bank (SPXSH440)
- Universal Marine Mounting Plate (SEADASH3W / SEADASH3B)
- Marine USB & AUX Extension (SMRAUXUSB3)
- Marine Grade RCA Leads (SMRCA1 / SMRCA 3 / SMRCA 6)
- PowerSport Amplifiers (SPX350X2 / SPX700X4)
Whats included?
The Stinger SPXM1 includes the following
- Source Unit
- Source Unit Trim Plate
- Mounting Bracket
- Mounting Screws
- Threaded Studs
- Flange Nuts
- Power / Speaker Harness
Product Overview Video
| Size |
2.7" Color TFT optical bonded Display |
|---|---|
| Battery Voltage |
9V DC – 18V DC |
| Bluetooth Support |
Version: 3.0+EDR, A2DP 1.3 |
| FM Tuner |
87.9MHz to 107.9MHz Usable sensitive 0dB (mono S/N: 30dB) SNR: 65dB |
| AM Tuner |
530KHz to 1710KHz Usable sensitive 0dB (mono S/N:20dB) SNR 58dB |
| Audio |
Adjustable gain for each source, Continuous power output: 25W x 4ch/4Ω 20Hz to 20KHz, Crossover: High Pass, Low Pass, Equalizer: 7 Band Graphic, Frequency Response: 20-20kHz, Peak power output: 50W x 4ch/4Ω, Preamp Voltage: 2 Volts, RCA Outputs: 2 Pair(Front, Rear or Sub), Speaker Impedance: 4 ohm |
| RCA Pre-Outs |
2 Pair(Front, Rear or Sub) |
| USB |
1 AMP Output, 255 Folders Max, 32GB Max, 999 Songs Max, File Types: MP3/WMA/FLAC, Location: Rear |
| Video System |
Camera Inputs Accept NTSC OR PAL video formats, External & Internal Trigger |
| SKU | SPXM1 |
|---|---|
| Barcode # | 609098832533 |
| Brand | Stinger |
| Shipping Weight | 2.0000kg |
