GCG's TDX Turbocharger range is designed as a direct bolt on replacement, ideal for those people looking for added towing power. All TDX Turbochargers are built in house, using a specifically designed billet compressor wheel, providing 20% more airflow over a factory unit. This results in a heathy gain in overall torque and horsepower.

To gain the full potential of the TDX range of turbochargers, we recommend having the vehicle tuned to meet safe EGT's & lambda readings, and fitting upgrade supporting components, such as higher flowing exhaust, upgrade intercooler, upgrade hot and cold side piping and upgrade air inlet piping/airbox.

Turbocharger Information:

• This turbocharger is a brand new genuine Garrett turbocharger, that is modified in house with a specifically designed billet aluminium full blade compressor wheel
• Supplied with gaskets for re-fitment
• Comes with 12 months warranty
• 100% Bolt-On

Brand: GCG TDX Garrett
Type: GTB1749V

Application: Upgrade Bolt On for

• Ford Ranger PX (All Variants ie: XL, XL Plus, Hi-Rider, Wildtrack etc) 09/2011 - 08/2015
• Mazda BT-50 UP Chassis (All Variants ie: XT, GT, XTR Freestyle Cab etc) 11/2011 - 08/2015
• Ford Transit Duartorq 2.2L SOHC 03/2012>
• This turbocharger suits models to 06/2015, however we have found some cross-over to the later model 1000-01597. We recommended you check the part number on the turbocharger prior to ordering.

Engine Manufacturer: Ford
Engine Model: DURATORQ SOHC 2.2L Euro 5 130PS CRD
Fuel Type: Diesel
OEM Part Number: BK3Q-6K682-CC,BK3Q-6K682-CB, BK3Q-6K682-PB, BK3Q-6K682-PC, 1717628, 1719695, U20313700A
Turbocharger Part Number: TDX854800-5001S
Previous Versions: 854800-5001S, 854800-5001, 854800-1, 854800-0001, 787556-0016, 787556-5016S, 787556-5016, 787556-5017, 787556-5017S, 787556-0017, 787556-5022S, 787556-5022, 787556-0022, 787556-22

Product Notes:

Gasket Kit Included
