Ford Radio Replacement Interface
Make installation of your new aftermarket radio or infotainment system easy in select Ford vehicles with the Plug & Play ConnectPRO Audi radio replacement solution from Stinger Australia
The Radio Replacement Solution
There's nothing worse than loosing your steering wheel control buttons when updating to the latest technology.
The SWI-FD01 from ConnectPRO from Stinger Australia allows easy retention of steering wheel audio control buttons with your new aftermarket radio or infotainment system.
Keep your eyes on the road and less time fumbling for the radio with ConnectPRO.
The Solid Connection
Each ConnectPRO radio replacement solution includes a Plug and Play interface for a easy and solid connection to your existing vehicle harness.
No need to strip back wires or chop off connectors in your vehicle allowing re-installation of your factory radio if ever required.
Feature Packed
The ConnectPRO SWI-FD01 features:
- Retains factory fitted steering wheel audio buttons
- 'Nav' or Multimedia outputs including:
Reverse Trigger
Park Brake
Speed Signal
Illumination Output
Suitable for vehicles with
- 40PIN Quadlock
What Do You Get?
The ConnectPRO SWI-FD01 kit includes
- Autoleads ControlPRO.2 CP2-UNI.2 Interface
- 40 PIN Quadlock Vehicle Plug and Play Harness
- Bare wire CP2-UNI.2 Harness
- Instruction Manual
Compatibility Notes
- Not compatible with vehicles that have ignition 12v in 40PIN Radio Connector
- Does not retain Amplified system
- Phone buttons cannot be retained in all vehicle models (if fitted)
- Voice Recognition (VR) Button feature not retained (if fitted)
- Multimedia Outputs (Reverse / Handbrake / VSS / Illumination) only available if data is present on vehicle network
- Designed for use with major branded head units including
Alpine, Clarion, Kenwood, JVC, Pioneer, Sony, Stinger plus more
| Plug & Play | YES – FACTORY CONNECTOR TO STANDARD ISO CONNECTOR |
|---|---|
| Retain Factory Steering Wheel Audio Controls? | YES – Will retain Steering Wheel Audio Controls with Select Aftermarket Radios |
| Retain Factory Amplifier? | NO |
| Retain Parking Sensors? | NO – If vehicle OEM radio was generating the parking sensor tones. If parking sensors are not part of the factory radio, they should not be effected |
| Vehicle Plug Style | 40PIN Quadlock Style Connector |
| Application Notes | Suits models WITHOUT 12v ignition wire in the vehicle 40PIN Quadlock harness |
| Vehicle Make | Vehicle Model | Vehicle Year + Vehicle Chassis Code |
|---|---|---|
| FORD | FIESTA | 2006 - 2008 (WQ) |
| FORD | FOCUS (Incl XR5) | 2005 - 2007 (LS-LT) |
| FORD | FOCUS (Incl XR5) | 2008 - 2011 (LV) |
| FORD | KUGA | 2011 - 2013 (1ST GEN) |
| FORD | MONDEO | 2007 - 2014 (MB - MC) |
| FORD | TRANSIT | 2007 - 2014 (VM) |
| SKU | SWI-FD01 |
|---|---|
| Barcode # | 9342270006506 |
| Brand | ConnectPRO |
| Shipping Weight | 1.5000kg |
Connectpro Swc Interface - Ford Can-Bus Quadlock
