Features

Easily add 4 fused circuits to the terminal of a battery.

Provides power to new accessories in your boat or vehicle.

Mounts on the battery terminal stud
Screw terminals for securing wires
Nylon insulated ring terminals included for each screw terminal
Accepts small format circuit labels
Insulating cover meets ABYC/USCG insulation requirements
Ignition Protected–meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment
Includes a 4-circuit negative busbar
Includes write on labels
Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals

Specifications

T Blade Battery Terminal Mount Fuse Block Kit
Circuits	4
Maximum Amperage	100A per block 30A per circuit
Maximum Voltage	32V DC
Bus Material	Tin-Plater Copper C11000
Mounting Hole	3/8″ [M10] stud
Screw Terminal Type	#8-32

SKU: BS-5024

$66.99 MATES’ RATE

Unlock Mates'Rate and Save. Login or Join Free

SAVE $5.01

REG $72.00

NSW, QLD & VIC Order Express by 17th Dec for Christmas delivery. T&Cs apply.

Ships in 7 days

$72.00 REG

$66.99 MATES’ RATE

Easily add 4 fused circuits to the terminal of a battery.

Provides power to new accessories in your boat or vehicle.

Mounts on the battery terminal stud
Screw terminals for securing wires
Nylon insulated ring terminals included for each screw terminal
Accepts small format circuit labels
Insulating cover meets ABYC/USCG insulation requirements
Ignition Protected–meets ISO 8846 and SAE J1171 for use in a gasoline engine compartment
Includes a 4-circuit negative busbar
Includes write on labels
Includes four 16-14 AWG and four 12-10 AWG Nylon insulated ring terminals

T Blade Battery Terminal Mount Fuse Block Kit
Circuits	4
Maximum Amperage	100A per block 30A per circuit
Maximum Voltage	32V DC
Bus Material	Tin-Plater Copper C11000
Mounting Hole	3/8″ [M10] stud
Screw Terminal Type	#8-32
