The Hi-Lift X-TREME is for the serious Hi-Lift® user, offering the "top of the line" all-cast version (48" or 60" sizes) with a special top winch-clamp-spreader attachment that provides the ultimate in multi-use functionality.
The X-TREME Top Clamp replaces the top clamp-clevis of the standard Hi-Lift® models and provides the ability to winch, clamp, and spread up to 5,000 lbs.
Features
- All-Cast Construction
- 7000lb (3175.14kg) Tested Capacity
- Available in 48", & 60" Heights. (122, & 152cm)
- Lifts, Winches, Clamps, & More
- A must-have for the serious Hi-Lift user!
- Tested and certified to meet applicable requirements of ASME B30.1-2015
|
XT-605 |
|
|
Size |
60” (152 cm) |
|
Min. Lift Height |
4.5" (11.43 cm) |
|
Max. Lift Height |
48.75" (123.8 cm) |
|
Overall Height |
61.75" (156.85 cm) |
|
Width |
5" (12.7 cm) |
|
Depth |
9.63" (24.46 cm) |
|
Rated Load (RL) |
4,660 lbs (2,113 kg) |
|
RL on upper 12" (30.5cm) |
2,660 lbs (1206 kg) |
|
Tested Load (TL) |
7,000 lbs (3,175 kg) |
|
TL on upper 12" (30.5cm) |
4,000 lbs (1,814 kg) |
|
Winching Capacity |
5,000 lbs (2,268 kg) |
|
Clamping Capacity |
5,000 lbs (2,268 kg) |
|
Weight |
31.31 lbs (14.2 kg) |
- Proven Hi-Lift gear for recoveries
- 60 inch rail for lifted rigs
- All-cast construction made to last
- 5,000 lb clamp and winch rating
- 4,660 lb rated load capacity
- Compact footprint for simple storage
- Model: Hi-Lift X-TREME XT-605
- Type: All-cast mechanical high-lift jack with top winch-clamp-spreader attachment
- Size / Rail length: 60" (152 cm)
- Overall height: 61.75" (156.85 cm)
- Minimum lift height: 4.5" (11.43 cm)
- Maximum lift height: 48.75" (123.8 cm)
- Width: 5" (12.7 cm)
- Depth: 9.63" (24.46 cm)
- Rated load (RL): 4,660 lbs (2,113 kg)
- Rated load on upper 12" (30.5 cm): 2,660 lbs (1,206 kg)
- Tested load (TL): 7,000 lbs (3,175 kg)
- Tested load on upper 12" (30.5 cm): 4,000 lbs (1,814 kg)
- Winching capacity: 5,000 lbs (2,268 kg)
- Clamping capacity: 5,000 lbs (2,268 kg)
- Construction: All-cast steel
- Weight: 31.31 lbs (14.2 kg)
- Compliance: Tested and certified to ASME B30.1-2015
Hi-Lift X-TREME Jack 60" (152 cm) unit only.
| SKU | XT-605 |
|---|---|
| Barcode # | OEBC716979 |
| Brand | Hi-Lift |
| Shipping Weight | 14.5000kg |
| Shipping Width | 0.130m |
| Shipping Height | 0.250m |
| Shipping Length | 1.550m |
| Shipping Cubic | 0.050375000m3 |
