The TAG 4" Drop Forged Tow Ball Mount provides ultimate durability. Forged from a single, solid piece of steel for an increased ball weight and tow rating of 450kg/4500kg. Designed to accompany the TAG Heavy Duty Towbar, fitting a 50mm Square Hitch Receiver and for use in drop or rise mode.
- Solid, 50mm x 50mm ION forged shank
- 70mm Ball Mount
- 241mm Long (Hitch Pin Hole to Tow Ball Hole)
- 100mm (4") drop/rise
- Can be mounted in Drop Mode or Rise Mode to raise or lower the tow ball
- 4500kg Gross Trailer Weight
- 450kg Ball Weight
- ADR 62/02 Compliant
- TAG Limited Lifetime Warranty
Tow Ball, R-Clip & Hitch Pin are sold separately. Always check your vehicle and towbar's maximum towing capacities.
- One piece forged steel construction
- 100mm drop or rise capability
- 4500kg GTW and 450kg ball rating
- Fits standard 50mm square hitches
- ADR 62/02 compliant for Aussie roads
- TAG limited lifetime warranty support
- Brand: TAG
- Tow ball mount type: 4" drop forged tow ball mount
- Hitch receiver size: 50mm square
- Shank type: solid ION forged shank
- Shank dimensions: 50mm x 50mm
- Ball mount size: 70mm
- Length (hitch pin hole to tow ball hole): 241mm
- Overall horizontal length: 375mm (approximate from diagram)
- Drop / rise: 100mm (4")
- Ball weight rating: 450kg
- Gross trailer weight (GTW) rating: 4500kg
- Material: forged steel
- Compliance: ADR 62/02 compliant
- Warranty: TAG limited lifetime warranty
- Compatible towbar style: TAG Heavy Duty Towbar with 50mm square hitch receiver
- Mount orientation: can be used in drop mode or rise mode
1 x TAG 4" Drop Forged Tow Ball Mount
(Tow ball, R-clip and hitch pin sold separately)
| SKU | UNTTBM454 |
|---|---|
| Barcode # | 9340407045404 |
| Brand | TAG |
| Shipping Weight | 8.0000kg |
