The Koyorad JR2817J radiator drops into Toyota Land Cruiser 200 Series UZJ200 models with the 4.7L V8, using a core that stands 590 mm high and 712 mm wide so you keep coolant temps in check when you tow or tackle long climbs. The 48 mm thick core gives plenty of contact area for heat to move out of the coolant, and the 38 mm inlet and 42 mm outlet match the factory hoses on Toy146PACAK setups.

The built-in transmission cooler runs to 390 mm across the base of the core, so the auto in your UZJ200 holds its own on hot days and slow tracks. The mounting pattern suits the Land Cruiser 200 engine bay, with dimensions mirroring the standard radiator so the fan shroud and brackets line up without custom work. It is straight-up replacement gear for 4.7L V8 2UZ-FE wagons from 2007-on that need cooling sorted before the next big trip.

• Direct replacement radiator for Toyota Land Cruiser 200 Series UZJ200 4.7L V8 auto (2007-on)
• Core height of 590 mm for strong frontal cooling coverage
• Core width of 712 mm matched to factory fan shroud area
• Core thickness of 48 mm to support stable heat transfer
• 38 mm inlet and 42 mm outlet to suit standard hoses
• Integrated 390 mm automatic transmission cooler section
• Pattern suits Toy146PACAK applications and mount points
• Suited to towing and touring use in Australian conditions
• Compatible with 2UZ-FE petrol V8 engine layout
• Koyorad brand replacement gear for performance cooling

Q: Does this radiator suit all Toyota Land Cruiser 200 Series models?

No, it suits UZJ200 models with the 4.7L V8 2UZ-FE and automatic transmission from 2007-on. Other engine or transmission combinations may use different radiator dimensions and hose sizes. Always match the 4.7L V8 engine code and auto transmission before ordering. Checking the Toy146PACAK reference against your existing radiator part number is a smart move.

Q: Is there an integrated transmission cooler in this radiator?

Yes, this radiator includes an internal transmission cooler section that measures 390 mm. This cooler connects to the automatic transmission fluid circuit. The integrated layout keeps the plumbing simple and uses the same basic routing as factory. It is important to flush the transmission cooler lines whenever a radiator is replaced to prevent contamination.

Q: What hose sizes does this radiator use?

The radiator uses a 38 mm inlet and a 42 mm outlet. These sizes suit the original hose dimensions on UZJ200 4.7L V8 automatic models. Replacing aged hoses while the radiator is out is usually worthwhile. Correct sizing helps avoid leaks and makes installation straightforward for your mechanic.

Q: How big is the radiator core compared to standard units?

The core on this Koyorad radiator measures 590 mm high, 712 mm wide and 48 mm thick. These figures align with OEM specifications for the Land Cruiser 200 UZJ200 4.7L V8 auto. Matching dimensions means the fan shroud, brackets and mounts should line up without modification. A correctly sized core supports stable engine temperatures under continuous load.

Suitable for Toyota Land Cruiser 200 Series UZJ200 with 4.7L V8 2UZ-FE engine and automatic transmission from 2007-on. Intended as a direct replacement radiator for Toy146PACAK applications. Professional installation is recommended and existing hoses and clamps should be checked for compatibility and condition.
