The Jayrad JR7308J radiator slots into Suzuki Vitara models from 1992 to 1996 with auto gear and keeps things in check on slow climbs and beach runs. The core stands 425 mm high and 490 mm wide so it lines up well with factory fan shrouds and airflow. A 27 mm core thickness and 325 mm transmission cooler give enough surface area to handle towing or loaded touring without drama.

Both inlet and outlet necks sit at 28 mm so your standard hoses match up without hunting for odd sizes. The layout mirrors factory mounting points which makes it a smart buy if your old unit is tired or blocked. This is straightforward cooling gear for real Aussie conditions from corrugated tracks to daily city runs. You get solid heat control without messing around with custom brackets or hoses.

• Jayrad replacement radiator for Suzuki Vitara 1992–1996 auto
• Core height of 425 mm for full frontal coverage
• Core width of 490 mm to match factory fan shroud
• Core thickness of 27 mm for balanced cooling efficiency
• 28 mm inlet diameter to suit standard upper hose
• 28 mm outlet diameter to suit standard lower hose
• Integrated 325 mm transmission cooler for automatic gearbox lines
• Suited to 4x4 and touring performance radiator category
• Direct style replacement for ageing or leaking factory radiator
• Compatible with automatic transmission Vitara models only

Q: Does this radiator include an integrated transmission cooler?

Yes, this radiator includes an integrated transmission cooler measuring 325 mm. That means the automatic transmission fluid can circulate through the built-in cooler instead of a separate unit. It keeps the install neat and close to factory layout. Just make sure the transmission lines are clean and correctly tightened during fitment.

Q: Will this fit a manual transmission Suzuki Vitara from the same years?

This specific radiator is listed for automatic transmission models only. Manual versions often use a different configuration without the same transmission cooler layout. Mixing them can lead to hose or line routing issues. Always match the radiator spec to the transmission type on the vehicle.

Q: Do I need new hoses for the 28 mm inlet and outlet?

The inlet and outlet diameters are 28 mm which matches standard hose sizing on compatible Vitara models. If your existing hoses are in good condition and designed for 28 mm necks they can usually be reused. Many owners still choose fresh hoses when changing a radiator to avoid future leaks.

Q: Is this radiator suitable for towing and long-distance touring?

The 425 mm by 490 mm core and 27 mm thickness give decent surface area for coolant and airflow. The 325 mm inbuilt transmission cooler also helps when the auto box works harder under load. For heavy towing you should still keep the cooling system well maintained and watch temperature gauges on long climbs.

• Suits Suzuki Vitara models built between 1992 and 1996 with automatic transmission
• Direct replacement radiator for factory unit on compatible Suzuki Vitara vehicles
• Includes integrated transmission cooler suitable for automatic transmission lines on specified models
• Professional installation recommended to confirm hose routing coolant capacity and fan shroud clearance on the vehicle
