This Jayrad RA701AL radiator suits Toyota RAV4 ACA21R autos from 2001-on and keeps engine and transmission temps under control when you get out there. The core measures 450 by 529 millimetres so it fills the factory opening without wasted airflow. A 45 millimetre thick core carries enough coolant for long climbs and slow work. Both inlet and outlet sit at 35 millimetres so your factory hoses slide straight on without drama. This setup runs an integrated transmission cooler in the tank so the auto stays in its comfort zone while you tackle heat and traffic. The 450 millimetre core height lines up with the stock shroud for predictable fan pull at idle. The 529 millimetre width spreads heat across the full nose of the RAV4 which matters on long summer highway runs. This Jayrad gear is a smart buy if you want known dimensions and straightforward fitment without custom brackets.

• Suits Toyota RAV4 ACA21R automatic models from 2001-on
• Jayrad RA701AL radiator with Toy60147 cross-reference
• Core height of 450 mm for strong airflow coverage
• Core width of 529 mm to fill factory opening
• Core thickness of 45 mm for added coolant capacity
• 35 mm inlet diameter to match OEM top hose
• 35 mm outlet diameter to match OEM bottom hose
• Integrated transmission cooler for automatic gearbox applications
• Direct-fit style compatible with factory shroud and fan
• Ideal replacement unit for ageing or leaking factory radiator

Q: Does this radiator include a built-in transmission cooler?

Yes, this radiator includes an integrated transmission cooler. The cooler sits inside the tank, using separate passages from the engine coolant. This lets the automatic transmission fluid shed heat without mixing with coolant. It keeps plumbing tidy and matches the factory RAV4 automatic setup.

Q: How can I confirm this radiator will fit my RAV4?

Match the dimensions and model code to your existing gear. Check your vehicle is a Toyota RAV4 ACA21R with automatic transmission from 2001-on. Measure your old core for around 450 mm height and 529 mm width with 35 mm hose necks. If these line up, you are looking at the right replacement radiator.

Q: Do I need new hoses or clamps with this radiator?

This radiator uses 35 mm inlet and outlet necks to suit the factory hoses. You can usually reuse hoses if they are still in good condition and not perished or swollen. Many people choose to replace aging hoses and clamps at the same time. That helps avoid future leaks once the new core is in.

Q: Is this radiator suitable for towing or long highway runs?

The 45 mm thick core and integrated transmission cooler support higher heat loads than a thinner unit. The 450 by 529 mm frontal area works well with the factory fan and shroud on long highway climbs. For typical towing weights within the RAV4 rating, this setup gives stable cooling capacity. Always keep coolant quality and airflow through the fins in good condition for best results.

Fits Toyota RAV4 ACA21R models from 2001-on with automatic transmission. Suits applications listed under Jayrad part number RA701AL and cross-reference Toy60147. Check the existing radiator core height of 450 mm and width of 529 mm plus 35 mm hose diameters against this unit before install. Use with the factory transmission cooler line connections integrated into the tank. Professional installation is recommended to avoid coolant or transmission fluid leaks.
