The Panel-Stereo from Fusion allows you to enjoy quality audio on board your boat from the convenience of a single unit – designed to save time and money with a quick and simple installation.
- Preconfigured Digital Signal Processing (DSP) technology for a superior listening experience.
- Hi-Fi audio reproduction through preconfigured DSP.
- Built-in Class-D amplifier delivers higher efficiency and greater output.
- Optimally tuned, sealed enclosure with two 3-inch speakers and passive bass radiator.
- Multiple mounting options available, including flush, flat and surface mounting.
- Control your music from a compatible smart device or Garmin watch.
FUSION DIGITAL SIGNAL PROCESSING
A technically superior listening experience made simple, Fusion DSP optimises the audio signal delivered to your Fusion system to produce superior sound quality at all volume levels.
PERFECTLY TUNED ENCLOSURE
The Panel-Stereo is brilliantly designed – combining built-in amplification, stereo source selection, two 3-inch speakers and a large surface passive bass radiator to deliver premium, optimised audio onboard from a single unit.
FUSION DIGITAL SIGNAL PROCESSING
A technically superior listening experience made simple, Fusion DSP optimises the audio signal delivered to your Fusion system to produce superior sound quality at all volume levels.
PERFECTLY TUNED ENCLOSURE
The Panel-Stereo is brilliantly designed – combining built-in amplification, stereo source selection, two 3-inch speakers and a large surface passive bass radiator to deliver premium, optimised audio onboard from a single unit.
SPECS
General |
|
| Dimension | 13.54"" x 6.1"" x 1.97"" (344 x 155 x 50 mm) |
|---|---|
| Weight |
2.54 lbs (1.15 kg) |
| Water rating | IP65 (when properly installed) |
| Operating temperature | 32° to 122° F (0° to 50° C) |
| Current (max) | 10 A |
Networking |
|
| Bluetooth® wireless range | Up to 10 metres (30 ft) |
|---|---|
| ANT® wireless range | Up to 10 ft (3 metres) |
| Wireless frequencies/protocols | Bluetooth®: 2.4 GHz @ +12 dBm nominal ANT®: 2.4 GHz @ +7 dBm nominal |
Audio |
|
| Amplifier | Class-D |
|---|
Electrical features |
|
| POWER INPUT | 10.8 - 16 VDC |
|---|---|
| Compass safe distance | 7.6"" (229 mm) |
Stereo features |
|
| Peak power | 140 watts |
|---|---|
| Rated power output (2 Ohm) | 43 watts RMS x 2 @ 14.4 V input < 1% THD |
| Built-in Digital Signal Processing (DSP) | Yes (preconfigured) |
| Control | Yes (smart device and Garmin watch) |
| Bluetooth® wireless technology | |
| ANT® wireless technology | |
| Multi-language interface | Chinese (Mandarin), Dutch, English, French, German, Italian, Japanese, Spanish |
| Software updates | USB |
| Warranty | 1year |
Sources |
|
| Supported sources | AM, FM, Bluetooth®, USB audio, iPhone®, iPod®, AUX x2, AOA |
|---|
Connections |
|
| Auxiliary inputs (RCA) | 2 |
|---|---|
| USB 2.0 ports | 1 |
| Antenna ports | 1 |
| Line out | 1 RCA output (AUX) |
IN THE BOX
- Fusion® Panel-Stereo
- Stereo trim
- Six 6-gauge, self-tapping stainless-steel screws
- Power wiring harness
- Documentation
- Compact panel stereo with twin speakers
- Peak 140 watt for cabin sound
- Runs on 10.8–16 VDC boat systems
- IP65 front face for marine spray
- Bluetooth and USB audio support
- Smart buy for tidy marine setups
- Dimensions: 13.54" x 6.1" x 1.97" (344 x 155 x 50 mm)
- Weight: 2.54 lbs (1.15 kg)
- Water rating: IP65 when properly installed
- Operating temperature: 32° to 122° F (0° to 50° C)
- Maximum current draw: 10 A
- Bluetooth wireless range: up to 10 metres (30 ft)
- ANT wireless range: up to 10 ft (3 metres)
- Wireless frequencies: Bluetooth 2.4 GHz @ +12 dBm nominal; ANT 2.4 GHz @ +7 dBm nominal
- Amplifier type: Class-D
- Power input: 10.8–16 VDC
- Compass safe distance: 7.6" (229 mm)
- Peak power: 140 W
- Rated power output (2 Ohm): 43 W RMS x 2 @ 14.4 V input < 1% THD
- Built-in DSP: preconfigured digital signal processing
- Control options: compatible smart device and Garmin watch
- Software updates: via USB
- Warranty: 1 year
- Supported sources: AM, FM, Bluetooth, USB audio, iPhone, iPod, AUX x2, AOA
- Auxiliary inputs: 2 x RCA
- USB ports: 1 x USB 2.0
- Antenna ports: 1
- Line out: 1 x RCA output (AUX)
- Integrated speakers: two 3" speakers with passive bass radiator
- Enclosure type: optimally tuned sealed enclosure
- Mounting options: flush, flat and surface mounting
- Fusion Panel-Stereo unit
- Stereo trim
- Six 6-gauge self-tapping stainless-steel screws
- Power wiring harness
- Documentation
| SKU | 010-02005-00 |
|---|---|
| Barcode # | 0753759197957 |
| Brand | Fusion |
| Shipping Weight | 2.1700kg |
| Shipping Width | 0.155m |
| Shipping Height | 0.050m |
| Shipping Length | 0.344m |
