OVERVIEW
MODERN, COMPACT AND ECONOMICAL
The MS-RA60 is the most economical marine stereo from Fusion yet, featuring modern aesthetics, Multi-Zone™ Technology in two zones and advanced connectivity options in a compact form factor.
Bonded LCD improves durability and protection against condensation and fogging.
Built-in Class-D amplifier delivers higher efficiency and greater output.
Enjoy convenient over-the-air software updates via Bluetooth® technology from the Fusion® Audio app1.
Multi-Zone Technology gives you control of two separate audio zones.
Control your music from your compatible smart device or Garmin watch.
IPX6 AND IPX7 INGRESS PROTECTION
Designed and engineered for the harsh marine environment, the MS-RA60 stereo has an IPX6- and IPX7-rated water-resistant front panel to perform and last on board.
MODERN DESIGN AND AESTHETICS
Providing uniformity across the helm, the black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy and elegant installation.
RETROFITTABLE
The MS-RA60 is designed to fit in the MS-RA55 mounting profile, eliminating the need to alter your existing cutout, reducing complexity when upgrading your stereo system.
Multiple source options
Take advantage of the multiple source options available, including Bluetooth technology, DAB+ radio, AM/FM radio and AUX connection.
BUILT-IN DAB TUNER
The built-in DAB tuner supports the latest DAB and DAB+ broadcasts, allowing you to enjoy high-quality digital radio streaming wherever DAB and DAB+ are supported. Simply connect an appropriate AM/FM antenna with no external DAB module required.
SPECS
General
| Dimension | 156 x 68 x 103.2 mm (6.18″ x 2.68″ x 4.06″) |
|---|---|
| Weight | 316 g |
| Water rating | IPX6 and IPX7 (front panel only, when properly installed) |
| Display | 2.3″ perimeter bonded monochrome dot matrix LCD |
| Operating temperature | 0° to 50° C |
| Current (max) | 15 A |
Networking
| Bluetooth® wireless range | Up to 10 metres (30 ft) |
|---|---|
| ANT® wireless range | Up to 10 ft (3 metres) |
| Wireless frequencies/protocols | Bluetooth®: 2.4 GHz @ +12 dBm nominal ANT®: 2.4 GHz @ +7 dBm nominal |
Audio
| Amplifier | Class-D (4 ohm) |
|---|
Electrical features
| POWER INPUT | 10.8 - 16 VDC |
|---|---|
| Compass safe distance | 150 mm (5.9″) |
Stereo features
| Peak power | 180 watts |
|---|---|
| Rated power output (4 Ohm) | 22 watts RMS x 4 @ 14.4 V input < 10% THD |
| Control | Yes (smart device and Garmin watch) |
| Multi-Zone™️ technology | 2 zones |
| Bluetooth® wireless technology | |
| ANT® wireless technology | |
| DAB+ ready | |
| Multi-language interface | Dutch, English, French, German, Italian, Spanish |
| Software updates | Over-the-air updates via Fusion-Link™ app |
Sources
| Supported sources | AM, FM, Bluetooth®, AUX x1 DAB+ (available in Europe and Australia only) |
|---|
Connections
| Auxiliary inputs (RCA) | 1 |
|---|---|
| Antenna ports | 1 |
| Speaker connections | 4 (2 zone amplified) |
| RCA Pre-out (left, right and subwoofer) | 1 zone (requires external amplification) |
| Line out | Zone 1: L + R (requires external amplification) |
| Subwoofer out | Zone 1 (requires external amplification) |
IN THE BOX
- Fusion® MS-RA60 Marine Stereo
- Mounting gasket
- Four 6-gauge, self-tapping screws
- Two screw covers
- Power and speaker wiring harness
- Auxiliary-in, line-out, and subwoofer-out wiring harnesses
- Documentation
COMPATIBLE DEVICES
Fusion® EL Series Marine Speakers
Fusion® FM Series Marine Speakers
Fusion® FM Series Marine Subwoofers
Fusion® Signature Series 3 Marine Speakers
Fusion® Signature Series 3 Marine Subwoofers
Fusion Signature Series 3 Marine Wake Tower Speakers
Fusion® Signature Series Marine Amplifiers
Fusion® SM Series Marine Speakers
Fusion® Sound-Panel
Fusion® XS Series Marine Speakers
Fusion® XS Series Marine Subwoofers
quatix® 6 Titanium
- Compact gear that frees up helm space
- Two-zone setup keeps deck and cabin separate
- Bonded LCD stays clear in glare and fog
- IPX6 and IPX7 rating suits wet decks
- Class-D amp made to last onboard
- Smart buy for expandable marine sound
- Dimensions: 156 x 68 x 103.2 mm
- Weight: 316 g
- Water rating: IPX6 and IPX7 (front panel only, when properly installed)
- Display: 2.3" perimeter bonded monochrome dot matrix LCD
- Operating temperature: 0° to 50° C
- Maximum current draw: 15 A
- Power input: 10.8 – 16 VDC
- Amplifier type: Class-D (4 ohm)
- Peak power: 180 W
- Rated power output: 22 W RMS x 4 @ 14.4 V input < 10% THD
- Multi-Zone audio: 2 zones amplified
- Bluetooth wireless range: up to 10 m (2.4 GHz @ +12 dBm nominal)
- ANT wireless range: up to 3 m (2.4 GHz @ +7 dBm nominal)
- Supported sources: AM, FM, Bluetooth, AUX x1, DAB+ (Europe and Australia only)
- Inputs and outputs: 1 x RCA AUX in, 1 x antenna port, 4 x speaker connections, 1 x RCA pre-out (L/R/sub), line out Zone 1 L+R, subwoofer out Zone 1 (all requiring external amplification)
- Compass safe distance: 150 mm
- Software updates: Over-the-air via Fusion-Link app
- User interface languages: Dutch, English, French, German, Italian, Spanish
Fusion® MS-RA60 Marine Stereo unit
Mounting gasket
Four 6-gauge self-tapping screws
Two screw covers
Power and speaker wiring harness
Auxiliary-in wiring harness
Line-out wiring harness
Subwoofer-out wiring harness
Documentation
| SKU | 010-02405-00 |
|---|---|
| Barcode # | 0753759250300 |
| Brand | Fusion |
| Shipping Weight | 0.8300kg |
