Description
An incredibly durable, quality constructed load tester. Capable of performing variable tests on 6, 12 or 24V batteries rated as high as 2000CCA. Large meters clearly display battery voltage and load simultaneously.
| SPECIFICATIONS | |||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||
Features
- Gear handles up to 1000A load
- Suits 6V, 12V and 24V batteries
- Meters show amps and volts together
- 1400mm leads reach most bays
- Buzzer keeps tests within limits
- Smart buy for regular battery checks
Specifications
- Voltage range: 6V / 12V / 24V lead acid batteries
- Test voltage range: 0–30V DC
- Battery capacity range: up to 2000CCA (320Ah)
- Test load type: adjustable carbon pile
- Test load current range: 0–1000A
- Maximum load "on" time: 20 seconds
- Recommended cool-down time between tests: 2 minutes
- Test time alert: buzzer sounds after 15 seconds
- Cable length: 1400mm
- Unit size: 350mm x 355mm x 175mm
- Weight: 8.4kg
- Part number: BLT300
- Projecta BLT300 6V/12V/24V carbon pile load tester unit
- Integrated analogue DC volts meter
- Integrated analogue DC amps meter
- Fixed power and load control knobs on front panel
- Pair of heavy-duty battery clamps (red positive and black negative) attached to cables
- Integrated carry handle on top of housing
| SKU | BLT300 |
|---|---|
| Barcode # | BLT300 |
| Brand | Projecta |
| Shipping Weight | 10.4200kg |
