Ventilation with the MaxxFan Deluxe Exhaust Fan for Your RV

RV ventilation has never been easier than with a MaxxFan deluxe exhaust van and has been used in the US RV market since 1988. The MaxxFan Plus and the MaxxFan Deluxe, both have a manual option and an electric opening option, and they also have a ceiling mounted control panel that is easy to use and read. The Maxxfan is the ultimate luxary when travelling in caravan or a van, with superior ventilation and 12v fan speed, never feel muggy again when the rain hits and there's no where to go.

Product Features:

• Removable flyscreen – simply twist the L-clamps and remove for cleaning

• Powerful 10-speed fan motor

• Fan can run even if the lid is closed (select ‘Ceiling Fan Mode’) and can be used in “intake” and “exhaust” modes

• Provides over 900CFM, keeping your RV cool and comfortable

• Twin lifting arms limit vibrations cause by wind when in the ‘open’ position

Specifications:

• Installs onto all standard 14” x 14” (356mm x 356mm) roof openings

• Amp Draw on High: 2.5A

• Amp Draw on Low: 0.16A

• Dimensions (closed): 589L x 421W x 128H (mm)

• Dimensions (open): 589L x 421W x 230H (mm)

• Installed Weight: 5.4kg

• Roof Thickness: 25mm (min) – 90mm (max

Frequently Asked Questions about the MaxxFan Deluxe

How much power does a MaxxFan Deluxe draw?

The MaxxFan Deluxe draws 2.5A on high speed and 0.16A on low speed, making it an efficient option for RV ventilation.

Can you use MaxxFan in the rain?

Yes, the MaxxFan Deluxe can be used in the rain. It includes a rain dome and can be used in "intake" and "exhaust" modes to ensure your RV stays comfortable even in wet weather.

What are the electrical requirements for MaxxFan?

The MaxxFan Deluxe operates on a 12v power supply, making it compatible with standard RV electrical systems.

Do I need to apply additional sealant around the fan?

No extra sealant is needed around the top of the fan housing. The Maxxfan Deluxe is designed with a built-in water management system that redirects moisture away. You’ll only need to seal the base ring during installation using butyl tape or the included sealing materials.

Can I drive with the vent open?

Yes, you can. The integrated hood stays secure while you’re on the road. It allows airflow even when driving, without the risk of damage or leaks.

Can the MaxxFan Deluxe pull air in as well as push it out?

Yes. The fan supports both intake and exhaust modes, so you can bring in fresh air or extract stale air with a simple setting.

How is the Maxxfan Deluxe better than older Maxxair vent covers?

Older vent covers were bolt-on additions that collected dirt and made cleaning harder. The Maxxfan Deluxe combines the fan and cover in one sealed unit. It’s easier to install, easier to clean, and looks neater on your roof.
